For Vieser floor drains, untrapped drains and extension rings when using waterproofing paint.
Compatible with all Vieser floor drains and extension rings.
Must be attached with the clamping ring supplied with the floor drain or extension ring.
Vieser tõsterõngad ja varuosad
Vieser tõsterõngad ja varuosad
Vieser extension rings and spare parts
Järjesta:
Kuva: Nimekirjana / Võrgustikuna
Vieser 51130 Hüdroisolatsioonikrae
Vieser membrane flange
HVAC No. 3319661
EAN 6418685511904
Technical specifications
Vieser No.
51190
HVAC No.
3319661
EAN
6418685511904
Package (box/pallet)
12/288
Package dimensions
40 x 3 x 30 cm
Package weight
0,2 kg
Material
TPE
Usage
Must be attached with the clamping ring supplied with the floor drain, untrapped drain or extension ring.
General information
For Vieser floor drains, untrapped drains and extension rings when using waterproofing paint.
Compatible with all Vieser floor drains and extension rings.
Tootekood: AKV51130
, Tarneaeg: 3-7 päeva
13,22 €
Vieser 51180 Tõsterõngas 12mm
Vieser low model extension ring 12 mm
HVAC No. 3318951
The package contains the extension ring, a white lip seal, a grey clamping ring and a white support ring.
Please note:
a grey clamping ring is included in the package. The grey clamping ring is meant to be used with this extension ring type only. A white clamping ring is supplied with all other Vieser extension rings and floor drains.
The white lip seal and grey clamping ring are meant to be used with a low extension ring only, and they are not compatible with other Vieser products.
A low extension ring must always be the uppermost extension ring and it cannot be extended with another extension ring.
Tootekood: AKV51180
, Tarneaeg: 3-7 päeva
35,58 €
Vieser 51183 Tõsterõngas 18mm
Vieser low model extension ring 18 mm
HVAC No. 3318952
The package contains the extension ring, a white lip seal, a grey clamping ring and a white support ring.
Please note:
a grey clamping ring is included in the package. The grey clamping ring is meant to be used with this extension ring type only. A white clamping ring is supplied with all other Vieser extension rings and floor drains.
The white lip seal and grey clamping ring are meant to be used with a low extension ring only, and they are not compatible with other Vieser products.
A low extension ring must always be the uppermost extension ring and it cannot be extended with another extension ring.
Tootekood: AKV51183
, Tarneaeg: 3-7 päeva
35,58 €
Vieser 51205 Tõsterõngas 25-88mm
Vieser extension ring 25-88mm
HVAC No. 3318415
Compatible with all Vieser floor drains. Installed below the waterproofing.
Raises the floor drain by 25–88 mm.
The package contains the extension ring, a grey lip seal and a white clamping ring.
Tootekood: AKV51205
, Tarneaeg: 3-7 päeva
13,22 €
Vieser 51206 Betoonivalu tõsterõngas ümmargusele kaanele
Vieser Distance ring
HVAC No. 3318314
EAN 6418685512062
To be used as the framework/extension of a round grating in tiled floors. Can only be used above the waterproofing.
(Above the waterproofing only)
Technical specifications
Vieser No.
51206
HVAC No.
3318314
EAN
6418685512062
Package (box/pallet)
20/480
Package dimensions
15 x 5 x 15 cm
Package weight
0,1 kg
Material
Polypropylene PP
Usage
To be used as the framework/extension of a round grating in tiled floors. Can only be used above the waterproofing.
General information
(Above the waterproofing only )
Tootekood: AKV51206
, Tarneaeg: 3-7 päeva
12,20 €
Vieser 51208 Tõsterõngas külgavadega 3x32 mm
Vieser extension ring with side inlets 3x32mm
HVAC No. 3318452
Compatible with all Vieser floor drains. Installed below the waterproofing.
Raises the floor drain by 66–91 mm.
Three 32-mm side inlets can be connected to the extension ring.
The package contains the extension ring, a grey lip seal and a white clamping ring.
Technical specifications
Vieser No.
51208
HVAC No.
3318452
EAN
6418685512086
Package (box/pallet)
22/176
Package dimensions
20 x 10 x 20 cm
Package weight
0,3 kg
Material
Polypropylene PP
Usage
To be installed into Vieser floor drains below the waterproofing. Three 32-mm side inlets can be connected to the extension ring.
General information
An extension ring that raises the floor drain by 66-91mm. The package contains the extension ring, a grey lip seal and a white clamping ring.
Tootekood: AKV51208
, Tarneaeg: 3-7 päeva
18,30 €
