for WP/PP102e
110 x 450 x 120 mm

Order numbers:
satin finished: 923139
highly polished: 923139-HGL
RAL-powder coated: 923139-RAL

for WP/PP102e
110 x 450 x 120 mm

Order numbers:
satin finished: 923139
highly polished: 923139-HGL
RAL-powder coated: 923139-RAL

300 x 58 x 40 mm

• Towel rail in solid, germ-reducing and easy-care stainless steel (AISI 303), satin finished.
  Further available surfaces: see below.
• Two concealed anti-theft wall disc mountings.
• Holder diameter 16 mm
  Towel rail diameter 12 mm
  Distance between mounting points 300 mm
• Mounting with two screws.
• Delivery includes fixing material.

• Weight (in kg): 0,50

450 x 58 x 40 mm

• Towel rail in solid, germ-reducing and easy-care stainless steel (AISI 303), satin finished.
  Further available surfaces: see below.
• Two concealed anti-theft wall disc mountings.
• Holder diameter 16 mm
  Towel rail diameter 12 mm
  Distance between mounting points 450 mm
• Mounting with two screws.
• Delivery includes fixing material.

• Weight (in kg): 0,60

600 x 58 x 40 mm

• Towel rail in solid, germ-reducing and easy-care stainless steel (AISI 303), satin finished.
  Further available surfaces: see below.
• Two concealed anti-theft wall disc mountings.
• Holder diameter 16 mm
  Towel rail diameter 12 mm
  Distance between mounting points 600 mm
• Mounting with two screws.
• Delivery includes fixing material.

• Weight (in kg): 0,80

530 x 936 x 135 mm
vertical version

• Nappy changer in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed, handle strip with glossy surface.
  Further available surfaces: see below.
• Easy to open and close with maintenance free lifting mechanism supported by gas struts.
• Table surface in grey polypropylene, molded, without any visible fixtures.
• TÜV-tested and certified according to
  DIN EN 1221-1: 2013
  DIN EN 1221-2: 2013
  AfPS GS 2014: 01 PAK
  Load capacity 15 kg, test load 150 kg;
  approved for public and private use.
• Wear parts can be replaced as modules.
• Installation dimensions: 532 x 938 x 110 mm
• Mounting: With four screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material.

• Weight (in kg): 26,7

Mini nagi, satiin

R/V teras AISI 303

Ø 16 x 22 mm

Wagner Ewar

Nagi 2-ne, satiin

R/V teras AISI 303

Ø 45 x 45 mm

Wagner Ewar

Nagi, satiin

R/V teras AISI 303

Ø 45 x 36 mm

Wagner Ewar

435 x 148 x 148 mm
for 1 paper roll Ø 125 x 390 mm

• Paper roll dispenser for nappy changer in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Designed for one standard paper roll with dimensions:
  Outer diameter max. 125 mm
  Width: max. 390 mm
  Core diameter: min. 40 mm.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable, hinged housing.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material.

• Weight (in kg): 3,8

435 x 148 x 148 mm
for 1 paper roll Ø 125 x 390 mm

• Paper roll dispenser for nappy changer in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Designed for one standard paper roll with dimensions:
  Outer diameter max. 125 mm
  Width: max. 390 mm
  Core diameter: min. 40 mm.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable, hinged housing.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material.

• Weight (in kg): 3,8

Ø 40 x 40 mm

• Floor door stop in solid, germ-reducing and easy-care stainless steel (AISI 303), satin finished, with rubber ring. Further available surfaces: see below.
• Height 40 mm
  Diameter 30 mm
  Rubber ring diameter 40 mm
• Concealed, centric, anti-theft floor mounting.
• Mounting with one screw.
• Delivery includes fixing material.

• Weight (in kg): 0,20

Kombineeritud Seebidosaator 950ml ja Lotion dosaator 950ml Wagner Ewar RST316L harjatud

125 x 89 x 45 mm

• Soap shell in solid, germ-reducing and easy-care stainless steel (AISI 303), satin finished.
  Further available surfaces: see below.
• Concealed anti-theft two-point rosette wall mounting.
• Holder diameter 16 mm
  Shell diameter 89 mm
  Height 18 mm
• Mounting with two screws.
• Delivery includes fixing material.

• Weight (in kg): 0,60

Ø 45 x 110 mm

• Wall-mounted door buffer in solid, germ-reducing and easy-care stainless steel (AISI 303), satin finished.
  Further available surfaces: see below.
• Concealed anti-theft two-point rosette wall mounting.
• Holder diameter 16 mm
  Length 110 mm
• With rubber buffer.
• Mounting with two screws.
• Delivery includes fixing material.

• Weight (in kg): 0,30

Ø 16 x 26 mm

• Wall-mounted door buffer in solid, germ-reducing and easy-care stainless steel (AISI 303), satin finished.
• Concealed, centric, anti-theft wall mounting.
• Holder diameter 16 mm
  Length 26 mm
• With rubber buffer.
• Mounting with one screw.
• Delivery includes fixing material.

• Weight (in kg): 0,10

Ø 45 x 233 x 107 mm

• Double reserve toilet roll holder, right angled, in solid, germ-reducing and easy-care stainless steel (AISI 303), satin finished.
  Further available surfaces: see below.
• Designed for up to two standard toilet rolls with dimensions:
  Outer diameter max. 125 mm
  Width max. 100 mm
  Core diameter min. 38 mm
• Concealed anti-theft two-point rosette wall mounting.
• Holder diameter 20 mm, length 233 mm.
• Mounting with two screws.
• Delivery includes fixing material.

• Weight (in kg): 0,70

Ø 45 x 333 x 107 mm

• Triple reserve toilet roll holder, right angled, in solid, germ-reducing and easy-care stainless steel (AISI 303), satin finished.
  Further available surfaces: see below.
• Designed for up to three standard toilet rolls with dimensions:
  Outer diameter max. 125 mm
  Width max. 100 mm
  Core diameter min. 38 mm
• Concealed anti-theft two-point rosette wall mounting.
• Holder diameter 20 mm, length 333 mm.
• Mounting with two screws.
• Delivery includes fixing material.

• Weight (in kg): 0,80

Ø 40 x 80 mm

• Reserve-toilet roll holder in solid, germ-reducing and easy-care stainless steel (AISI 303), satin finished.
  Further available surfaces: see below.
• Designed for one standard toilet roll with dimensions:
  Outer diameter max. 125 mm
  Width max. 100 mm
  Core diameter min. 38 mm
• Concealed, centric, anti-theft wall disc mounting.
• Holder diameter 16 mm, length 80 mm.
• Mounting with one screw.
• Delivery includes fixing material.

• Weight (in kg): 0,20

150 x 92 x 44 mm

• Toilet roll holder in solid, germ-reducing and easy-care stainless steel (AISI 303), satin finished.
  Further available surfaces: see below.
• Designed for one standard toilet roll with dimensions:
  Outer diameter max. 125 mm
  Width max. 100 mm
  Core diameter min. 38 mm
• Concealed anti-theft two-point rosette wall mounting.
• Holder diameter 16 mm
  Width 150 mm
• Mounting with two screws.
• Delivery includes fixing material.

• Weight (in kg): 0,40

120 x 89 x 45 mm

• Ashtray in solid, germ-reducing and easy-care stainless steel (AISI 303), satin finished.
  Further available surfaces: see below.
• Concealed anti-theft two-point rosette wall mounting.
• Holder diameter 16 mm
  Dish diameter 89 mm
  Height 18 mm
• Mounting with two screws.
• Delivery includes fixing material.

• Weight (in kg): 0,60

Ukse stopper konksuga, satiin

R/V teras AISI 303

Ø 45 x 76 mm

Wagner Ewar

R/V teras AISI 303

Wagner Ewar

for WP102e-7S
220 x 25 x 255 mm

Order numbers:
satin finished: 923133
RAL-powder coated: 923133-RAL

300 x 500 x 300 mm
950 ml tank

• Hygiene station consisting of a sensor-disinfectant dispenser and a table-stand in robust, germ-reducing and easy-care stainless steel.
• Visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Sensor-disinfectant dispenser in stainless steel (AISI316L); all corners fully welded.
  • With EWAR® eModule touch-free operated disinfectant pump with 950 ml tank.
  • Designed for standard disinfectants.
  • Inspection slot to indicate fill level.
  • Accessible for refilling through lockable, hinged housing.
  • Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
  • eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  • Wear parts can be replaced as modules.
  • Delivery includes batteries.
• Table-stand in stainless steel (AISI304)
  • Base plate with rubber feet and removable receptacle.
  • Intended for free installation.

• Weight (in kg): 5,6

400 x 1350 x 400 mm
950 ml tank

• Hygiene station consisting of a sensor-disinfectant dispenser and a floor-stand in robust, germ-reducing and easy-care stainless steel.
• Visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Sensor-disinfectant dispenser in stainless steel (AISI316L); all corners fully welded.
  • With EWAR® eModule touch-free operated disinfectant pump with 950 ml tank.
  • Designed for standard disinfectants.
  • Inspection slot to indicate fill level.
  • Accessible for refilling through lockable, hinged housing.
  • Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
  • eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  • Wear parts can be replaced as modules.
  • Delivery includes batteries.
• Floor-stand in stainless steel (AISI304)
  • Base plate with rubber feet.
  • Intended for free floor installation.

• Weight (in kg): 10,3

380 x 1350 x 380 mm
950 ml tank

• Hygiene station consisting of a sensor-disinfectant dispenser and a floor-stand in robust, germ-reducing and easy-care stainless steel.
• Visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Sensor-disinfectant dispenser in stainless steel (AISI316L) with rounded vertical corners.
  • With EWAR® eModule touch-free operated disinfectant pump with 950 ml tank.
  • Designed for standard disinfectants.
  • Inspection slot to indicate fill level.
  • Accessible for refilling through lockable, hinged housing.
  • Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
  • eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  • Wear parts can be replaced as modules.
  • Delivery includes batteries.
• Floor-stand in stainless steel (AISI304)
  • Base plate with rubber feet.
  • Intended for free floor installation.

• Weight (in kg): 10,1

WC hari+seinakinnitus

R/V teras AISI 303, satiin

Wagner Ewar
