Intra настенная хозяйственная раковина VK 655x505x250mm, Н/Р сталь

Отделитель пластика Elcee 255, 9L, Н/Р сталь, AISI 304

Overall dimension in mm Ø300 x 382 Inlet dimension in mm 1.5" Outlet dimension in mm 1.5" Material AISI 304 Material thickness in mm 1.5 Gross weight in kg 7.70

Артикул: EL255-GIPS-01 , Время доставки: 3-4 недели

1135,00 €

Антивандалльная душевая пьезо кнопка Н/Р сталь, для смешанной воды, без адаптора

	AUS 11 Pressure button-controlled shower for heat regulated water

AUS 11 is a new type of shower fitting for single shower control. The fitting is designated for premixed water – with one water inlet and shower outlet elbow. Water is released and closed by an anti-vandal pressure button connected to electronics and an electromagnetic valve. The fitting is covered by a rust-free anti-vandal cover to prevent damage.

The mounting system has been designed so as to make removing the cover without using tools impossible with no bolt or screw being visible. The cover can be "pushed into" the wall level even if the mount box has been walled to an incorrect depth.

AUS 11 is identical to AUS 1P with a different design and very resistant cover sheet.

Electronics can work in two modes:

1) The button works on the START/STOP basis – water release/closing. If the water is not turned off upon the time adjusted by the user or manager (e.g. 20 seconds), the electronic system itself instructs water stopping. The user must press again to start water running. This significantly saves water as the user reduces the showering time.

2) The button works on the START/STOP basis. After the time adjusted by the manager (e.g. 3 minutes) expires there is a forced break when water cannot be released. During this time, the user is forced to leave the shower or wait. This prevents needless showering – water wasting.

Basic technical information
Water input:	G 1/2“
Water pressure:	1 - 10 Bar (0,1 – 1,0 MPa)
Time of water flow:	10 s – 42,5 min in mode 1
	0 s - 42,5 min in mode 2
Power supply:	12 V, 50 Hz
Power requirement:	6 VA
Source of power supplz:	ZAC 1/20 (max. 3× AUS 11)
	ZAC 1/50 (max. 8× AUS 11)
Weight:	2,0 kg

Requirements for setting up the construction
Water installation set up as per picture Set-up alcove 150 x 75 mm for installation casket Set-up cable for power supply – 12 V, 50 Hz from source of power supply ZAC

Complete delivery
installation casket input and output bolting electromagnetic valve spherical valve covering metal plate with piezo button electronics

Made to order
SP 1 – shower arm with water flow of 9 l/min SP 2 – shower arm with water flow of 7 l/min SP 3 – shower arm with water flow of 7 l/min ZAC - source of power supply 12V, 50Hz

Figure

A -	water inlet G 1/2"
C -	electricity supply cable 12 V, 50 Hz
G -	water outlet into shower armG 1/2"

Download information about the product
AUS 11 data for projectants - ( 84 kB )

Артикул: AZP-AUS 11 , Время доставки: 3-4 недели

375,00 €

Питьевой фонтан настенный сенсорный для бассейнов Н/Р сталь AISI316(бассейны) 12V/50Hz

AFO 01.Yst. steel sensor controlled drinking fountain

AFO 01.Y is st. stainless wall hung drinking fountain controlled by sensor. Water runs after disrupting the scanning zone.

Fountain is made by welding all components together.

Fountain is suppplied with safety power 12 V, 50 Hz from power supply ZAC (AFO 01.Y) or with 4x AA battery (AFO 01.YB).

Material is standardly st. steel AISI 304 or can be AISI 316 (AFO 01.Y.CL or AFO 01.YB.CL).

St. steel driking fountain AFO 01.Y is based on favourite model AFO 01 with manual control.

The sensor, located on the right side of the fountain, is reacting on the approach of the user. Water starts to run from the nozzle, located in the middle of the fountain bowl, and runs over the time when the user´s head is in the scanning zone (max. 30 sec.) + preset time (max. 4 sec.) to clean the nozzle.

Package contents

st. steel drinking fountain
nozzle
sensor and electronic
electromagnetic valve
connecting flexible hose
corner valve with filters
siphon
mounting material

water inlet	G 1/2"
water pressure	1 - 10 Bar (AFO 01.Y; AFO 01.Y.CL)
	2 - 8 Bar (AFO 01.YB; AFO 01.YB.CL)
outlet	d = 40 mm
bowl inner dimension	d = 245 mm
weigth	4 kg
suppply	12 V, 50 Hz (AFO 01.Y; AFO 01.Y.CL)
	6 V - 4 x AA battery (AFO 01.YB; AFO 01.YB.CL)
power supply	ZAC 1/20 (max. 3 x AFO 01.Y ; AFO 01.Y.CL)

Артикул: AZP-AFO01.YCL , Время доставки: 3-4 недели

1159,00 €

Питьевой фонтан напольный/настенный с наполнителем для бутылки ,механический Н/Р сталь AISI304

AFO 01.SL

drinking fountain with spout for filling bottles designed to stand and to be attached to wall

AFO 01.SL is a drinking fountain with spout for filling bottles designed to stand and to be attached to wall. Water runs for the time for which the valve is pressed plus the pre-set period after it is released; thus the jet can be rinsed. Second pressure valve serves for bottle filling.

In standard version the fountain is produced with a niche suitable for filling the bottle of 0.7 l. Fliountain with a niche for filling the botlles of 1.5 l can be made on order.

Water supply is provided by a flexible hose, trap comprises an elastic flexible couple. Flexible design of water supply and outflow allows variable and easy connection of the drinking fountain as well as its dismounting.

TAutomatic drinking fountain (with a sensor) can be supplied per order.

AFO 01.SL is manufactured from the stainless steel AISI 304. Other materials (e.g. AISI 316) possible on order.
For cleaning we recomnned WÜRTH detergents – material preservation (no. 0893 121 K) and material cleaning (no. 893 121 1).

Package contents

Stainless housing with cone
Pressure valve with jet
Pressure valve for bottle filling
Flexible hose outflow
Fixing and connecting material

dimensions	330 x 900 x 365 mm
water outlet	d = 40 mm
water inlet	G 1/2"
water pressure	2 - 6 Bar, recommended 3 Bar
weight	12 kg

Set up water outlet d = 40 mm
Set up water inlet G 1/2"

Артикул: AZP-AFO01.SL , Время доставки: 3-4 недели

1917,00 €
