Vieser extra low flow drain 605861 замок мембрана для водяного трапа

Vieser One 52641 горизонтальный сухой трап 32/40

Vieser One 52641 горизонтальный сухой трап 32/40

Vieser One 52641 Horisontaalne kuivtrapp 32/40

Vieser One untrapped drain DN32/40 without support legs

HVAC No. 3315942

Suitable for sewerage systems for regular wastewater.

The Vieser One untrapped drain is part of the Vieser floor drain system.

The untrapped drain can be used with a Vieser extension rings, waterproofing flange or gratings.

The package contains the untrapped drain, protective lid, a clamping ring, a seal and a clamping ring installation tool.

An untrapped drain does not include a water trap. Untrapped drain must be connected to a floor drain with a water trap or other form of water trap. Can be used in a sauna, for example. Cannot be used under a shower.

You can download water proofing pictures as a PDF & DWG file.

Vieser’s drain and cover combination comes with a 10-year system guarantee.

Vieser untrapped drain is compatible with Vieser design floor drains:

Technical specifications

Vieser No.

52641

HVAC No.

3315942

EAN

6418685526410

Package (box/pallet)

15/180

Package dimensions

24 x 14,5 x 22,5 cm

Package weight

0,54 kg

Material

Polypropylene PP

Usage

Suitable for sewerage systems for regular wastewater.

Flow

0,6l/s

General information

The Vieser One untrapped drain is part of the Vieser floor drain system. The untrapped drain can be used with a Vieser extension ring, waterproofing flange or grating.

The package contains the untrapped drain, protective lid, a clamping ring, a seal and a clamping ring installation tool. An untrapped drain does not include a water trap. Untrapped drain must be connected to a floor drain with a water trap or other form of water trap. Can be used in a sauna, for example. Cannot be used under a shower.

Артикул: AKV52641 , Время доставки: 3-7 дней

25,42 €

Vieser One 52630 вертикальный трап 75 3x32/40

Vieser One 52630 Vertikaaltrapp 75 3x32/40

Vieser One vertical floor drain DN 75 3×32/40

HVAC No. 3315935

Suitable for sewerage systems for regular wastewater.

The Vieser One vertical floor drain is part of the Vieser floor drain system.

The floor drain can be used with a Vieser extension rings, waterproofing flange or gratings.

The drain includes three 32/40 mm side inlets that can be opened.

The package contains the floor drain, a water trap, a seal, a clamping ring and a clamping ring installation tool.

Technical specifications

Vieser No.

52630

HVAC No.

3315935

EAN

6418685526304

Package (box/pallet)

15/120

Package dimensions

20 x 25 x 20 cm

Package weight

0,65 kg

Material

Polypropylene PP

Usage

Suitable for sewerage systems for regular wastewater.

Flow

2,3l/s

General information

The floor drain is compatible with Vieser extension rings, distance rings, waterproofing flange and grating system.

The drain includes three 32/40 mm side inlets that can be opened. The package contains the floor drain, a water trap, a seal, a clamping ring and a clamping ring installation tool.

Артикул: AKV52630 , Время доставки: 3-7 дней

42,70 €

Vieser 51205 регулирующие кольцо 25-88mm

Vieser 51205 Tõsterõngas 25-88mm

Vieser extension ring 25-88mm

HVAC No. 3318415

Compatible with all Vieser floor drains. Installed below the waterproofing.

Raises the floor drain by 25–88 mm.

The package contains the extension ring, a grey lip seal and a white clamping ring.

Артикул: AKV51205 , Время доставки: 3-7 дней

13,22 €

Vieser 51206 удлинняющее кольцо для заливки в бетон под круглую крышки

Vieser 51206 Betoonivalu tõsterõngas ümmargusele kaanele

Vieser Distance ring

HVAC No. 3318314

EAN 6418685512062

To be used as the framework/extension of a round grating in tiled floors. Can only be used above the waterproofing.

(Above the waterproofing only)

Technical specifications

Vieser No.

51206

HVAC No.

3318314

EAN

6418685512062

Package (box/pallet)

20/480

Package dimensions

15 x 5 x 15 cm

Package weight

0,1 kg

Material

Polypropylene PP

Usage

To be used as the framework/extension of a round grating in tiled floors. Can only be used above the waterproofing.

General information

(Above the waterproofing only )

Артикул: AKV51206 , Время доставки: 3-7 дней

12,20 €

Vieser регулируемая рама 51280 197x197 mm RST

Vieser reguleeritav terasraam 51280 197x197 mm RST

Roostevaba teras

Vieser adjustable stainless steel frame 197 x 197

HVAC No. 3316229

Adjustable stainless steel frame 197×197 mm
Suitable for use with all Vieser 197×197 mm stainless steel gratings
To make tilework installation easier, the frame can be adjusted max 15 mm toeach direction. The complete adjustment range is 30 mm
Professional’s choice

Vieser’s drain and cover combination comes with a 10-year system guarantee.

(PDF)Vieser round and square grating in tiled floor

(DWG)Vieser round and square grating in tiled floor

Technical specifications

Vieser No.

51280

HVAC No.

3316229

EAN

6418685512802

Package (box/pallet)

15/600

Package dimensions

22,5 x 1,5 x 22 cm

Package weight

0,165 kg

Material

Stainless steel (AISI 304)

Usage

To facilitate the installation of the tiling, the frame can be adjusted by a maximum of 15 mm in any direction. The total adjustment range is 30 mm.

General information

The package contains an adjustable steel frame. To facilitate the installation of the tiling, the frame can be adjusted by a maximum of 15 mm in any direction.

Артикул: AKV51280 , Время доставки: 3-7 дней

36,60 €
