Бесконтактные электронные сенсорные смесители Delabie BINOPTIC - Black Magic
DELABIE BINOPTIC уже был выбран и установлен в различных общественных местах по всему миру — в международном аэропорту Абу-Даби, в башне Incity Tower в Лионе, в Метрополисе Лилля в Европе, в новом культурном центре Tai Kwun (Гонконг), в башне Majunga (Париж) — это стильная и функциональная серия, специально разработанная для общественных и деловых помещений.
BLACK MAGIC - MATTE BLACK BINOPTIC BASIN TAP LINK Kataloogi
Dealabie дозатор мыло/гидроалкoгольный гель 1 L бесконтактный сенсорный Н/Р сталь чёрный
Dealabie dosaator seebi/hydroalcoholic gel 1 L kontaktivaba sensoriga R/V teras must
Wall-mounted electronic liquid soap dispenser, 1 litre
Ref. 512066BK
Liquid soap or hydroalcoholic gel dispenser.
Vandal-resistant model with lock and standard DELABIE key.
No manual contact: hands are automatically detected by infrared cell
(detection distance can be adjusted).
Bacteriostatic 304 stainless steel cover.
One-piece hinged cover for easy maintenance and better hygiene.
No waste pump dispenser: dispenses 0.8ml
(can be adjusted up to 7 doses per activation).
Option of operation in anti-clogging mode.
Automatic soap dispenser: 6 AA -1.5V (DC9V) batteries supplied, integrated in the soap dispenser body.
Low battery indicator light.
Tank with large opening: easy to refill soap from large containers.
Window allows soap level to be checked.
304 stainless steel with matte black finish.
Stainless steel thickness: 1mm.
Capacity: 1 litre.
Dimensions: 90 x 105 x 256mm.
For vegetable-based liquid soap with a maximum viscosity of 3,000 mPa.s.
Compatible with hydroalcoholic gel.
CE marked.
TECHNICAL CHARACTERISTICS
Wall-mounted electronic liquid soap dispenser, 1 litre
Ref. 512066BKSupply | 6 x AA batteries |
Technology | Infrared sensor |
Height | 256mm |
Depth | 90mm |
Width | 105mm |
Volume | 1 litre tank |
Thickness | 1mm |
Finish | Matte black 304 stainless steel |
Adjustable mirror with handle
Ref. 510202C
Tilting glass mirror with handle for easy adjustment those in a seated position or in a wheelchair.
For combined installation: can be used from sitting or standing position.
Quick and easy to install: simply clip into place.
Anti-theft lock.
Metallised anthracite tab handle.
Mirror made from 6mm Securit safety glass.
Mirror dimensions: 500 x 600mm.
Can be tilted up to 20°.
TECHNICAL FEATURES
Adjustable mirror with handle
Ref. 510202C
Height | 500mm |
---|---|
Depth | 84mm |
Width | 630mm |
Width to the wall | 70mm |
Thickness | 6mm |
Finish | Metallised anthracite |
Delabie бесконтактный электронный кран на смешанную воду 170mm 388035 M3/8" BINOPTIC TAP 230/12V матовый чёрный
BLACK BINOPTIC electronic tap
Ref. 388035Independent IP65 electronic control unit.
230/12V mains supply with transformer.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 to 6 lpm.
Scale-resistant flow straightener.
Adjustable duty flush (pre-set flush ~60 seconds every 24 hours after last use).
Active, infrared presence detection, sensor at the end of the spout optimises detection.
Chrome-plated brass body.
Matte black chrome finish.
PEX flexible with filter and solenoid valve M3/8".
Fixing reinforced by 2 stainless steel rods.
Anti-blocking security.
Spout with smooth interior and low volume of water (reduces bacterial development).
Drop height: 170mm for semi-recessed washbasins.
Suitable for people with reduced mobility.
TECHNICAL CHARACTERISTICS
BLACK BINOPTIC electronic tap
Ref. 388035Supply | Main supply 230/12V |
Connector | M3/8" |
Technology | Electronic |
Drop height | 170mm |
Spout length | 175mm |
Flow rate | 3 lpm |
Finish | Matte black chrome |
Delabie бесконтактный электронный кран на смешанную воду 170mm 488035 M3/8" BINOPTIC TAP 6V матовый чёрный
Delabie elektrooniline kraan eelsegatud veele 170mm 488035 M3/8" BINOPTIC TAP 6V matt must
BLACK BINOPTIC electronic tap
Ref. 488035
Independent IP65 electronic control unit.
123 6V Lithium batteries.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.
Scale-resistant flow straightener.
Adjustable duty flush (pre-set flush 60 seconds every 24 hours after last use).
Active, infrared presence detection, sensor at the end of the spout optimises detection.
Chrome-plated brass body.
Matte black chrome finish.
PEX flexible with filter and solenoid valve M⅜".
Fixing reinforced by 2 stainless steel rods.
Anti-blocking security.
Spout with smooth interior and low water volume (reduces bacterial development).
Drop height: 170mm for semi-recessed washbasins.
Suitable for people with reduced mobility.
TECHNICAL CHARACTERISTICS
BLACK BINOPTIC electronic tap
Ref. 488035Supply | 6V batteries |
Connector | M3/8" |
Technology | Electronic |
Drop height | 170mm |
Spout length | 175mm |
Flow rate | 3 lpm |
Finish | Matte black chrome |
Delabie бесконтактный электронный кран на смешанную воду 250mm 398035 M3/8" BINOPTIC TAP 230/12V матовый чёрный
Delabie elektrooniline kraan eelsegatud veele 250mm 398035 M3/8" BINOPTIC TAP 230/12V matt must
BLACK BINOPTIC electronic tap
Ref. 398035
Independent IP65 electronic control unit.
230/12V mains supply with transformer.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.
Scale-resistant flow straightener.
Adjustable duty flush (pre-set flush 60 seconds every 24 hours after last use).
Active, infrared presence detection, sensor at the end of the spout optimises detection.
Chrome-plated brass body.
Matte black chrome finish.
PEX flexible with filter and solenoid valve M⅜".
Fixing reinforced by 2 stainless steel rods.
Anti-blocking security.
Spout with smooth interior and low water volume (reduces bacterial development).
Drop height 250mm, for countertop washbasins.
Suitable for people with reduced mobility.
TECHNICAL CHARACTERISTICS
BLACK BINOPTIC electronic tap
Ref. 398035Supply | Mains supply 230/12V |
Connector | M3/8" |
Technology | Electronic |
Drop height | 250mm |
Spout length | 185mm |
Flow rate | 3 lpm |
Finish | Matte black chrome |
Delabie бесконтактный электронный кран на смешанную воду 250mm 498035 M3/8" BINOPTIC TAP 6V матовый чёрный
Delabie elektrooniline kraan eelsegatud veele 250mm 498035 M3/8" BINOPTIC TAP 6V matt must
BLACK BINOPTIC electronic tap
Ref. 498035
Independent IP65 electronic control unit.
Battery-operated with 123 6V Lithium batteries.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.
Scale-resistant flow straightener.
Adjustable duty flush (pre-set flush 60 seconds every 24 hours after last use).
Active, infrared presence detection, sensor at the end of the spout optimises detection.
Chrome-plated brass body.
Matte black chrome finish.
PEX flexible with filter and solenoid valve M⅜".
Fixing reinforced by 2 stainless steel rods.
Anti-blocking security.
Spout with smooth interior and low water volume (reduces bacterial development).
Drop height 250mm for countertop washbasins.
Suitable for people with reduced mobility.
TECHNICAL CHARACTERISTICS
BLACK BINOPTIC electronic tap
Ref. 498035Supply | 6V batteries |
Connector | M3/8" |
Technology | Electronic |
Drop height | 250mm |
Spout length | 185mm |
Flow rate | 3 lpm |
Finish | Matte black chrome |
Delabie kontaktivaba elektronik kraan eelsegatud/külma matt must BINOPTIC TAP 230/12V
BLACK BINOPTIC electronic tap
Ref. 378035
Independent IP65 electronic control unit.
230/12V mains supply with transformer.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 to 6 lpm.
Scale-resistant flow straightener.
Adjustable duty flush (pre-set flush ~60 seconds every 24hr after last use).
Active, infrared presence detection, sensor at the end of the spout optimises detection.
Chrome-plated brass body.
Matte black chrome finish.
PEX flexible with filter and solenoid valve M3/8".
Fixing reinforced by 2 stainless steel rods.
Anti-blocking safety.
Spout with smooth interior and low volume of water (reduces niches where bacteria can develop).
Suitable for people with reduced mobility.
TECHNICAL CHARACTERISTICS
BLACK BINOPTIC electronic tap
Ref. 378035Supply | Mains supply 230/12V |
Connector | M3/8" |
Technology | Electronic |
Drop height | 90mm |
Spout length | 125mm |
Flow rate | 3 lpm |
Finish | Matte black chrome |
Delabie бесконтактный электронный кран на смешанную воду матовый чёрный BINOPTIC TAP 6V
Delabie kontaktivaba elektronik kraan eelsegatud/külma matt must BINOPTIC MIX 6V
BLACK BINOPTIC electronic tap
Ref. 478035
Independent IP65 electronic control unit.
123 6V Lithium battery-operated.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 to 6 lpm.
Scale-resistant flow straightener.
Adjustable duty flush (pre-set flush ~60 seconds every 24hr after last use).
Active, infrared presence detection, sensor at the end of the spout optimises detection.
Chrome-plated brass body.
Matte black chrome finish.
PEX flexible with filter and solenoid valve M3/8".
Fixing reinforced by 2 stainless steel rods.
Anti-blocking safety.
Spout with smooth interior and low volume of water (reduces niches where bacteria can develop).
Suitable for people with reduced mobility.
TECHNICAL CHARACTERISTICS
BLACK BINOPTIC electronic tap
Ref. 478035Supply | 6V batteries |
Connector | M3/8" |
Technology | Electronic |
Drop height | 90mm |
Spout length | 125mm |
Flow rate | 3 lpm |
Finish | Matte black chrome |
Delabie бесконтактный электронный смеситель 170mm 388MCHB M3/8" BINOPTIC MIX 230/12V матовый чёрный
Delabie kontaktivaba elektronik segisti 388MCHB M3/8" BINOPTIC MIX 230/12V matt must
BLACK BINOPTIC MIX electronic mixer
Ref. 388MCHB
Independant IP65 electronic unit.
230/12V mains supply with transformer.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.
Scale-resistant flow straightener.
Adjustable duty flush (pre-set at 60 seconds every 24 hours after the last use).
Optimised active infrared presence detection at the end of the spout.
Body in chrome-plated brass.
Matte black chrome finish.
Fixings reinforced by 2 stainless steel rods.
PEX flexibles with filters and M3/8" solenoid valves.
Anti-blocking security.
Spout with smooth interior and low water volume (reduces niches where bacteria can develop).
Side temperature control lever with long lever and adjustable maximum temperature limiter.
Drop height: 170mm, for semi-recessed basins.
Suitable for people with reduced mobility.
TECHNICAL CHARACTERISTICS
BLACK BINOPTIC MIX electronic mixer
Ref. 388MCHBSupply | Mains supply 230/12V |
Connector | M3/8" |
Technology | Electronic |
Drop height | 170mm |
Spout length | 175mm |
Flow rate | 3 lpm |
Finish | Matte black chrome |
Delabie бесконтактный электронный смеситель 170mm 488MCHB M3/8" BINOPTIC MIX 6V матовый чёрный
Delabie kontaktivaba elektronik segisti 488MCHB M3/8" BINOPTIC MIX 6V matt mustBLACK BINOPTIC MIX electronic mixer
BLACK BINOPTIC MIX electronic mixer
Ref. 488MCHB
Independent IP65 electronic control unit.
123 6V Lithium batteries.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.
Scale-resistant flow straightener.
Adjustable duty flush (pre-set flush 60 seconds every 24 hours after last use).
Active, infrared presence detection, sensor at the end of the spout optimises detection.
Chrome-plated brass body.
Matte black chrome finish.
PEX flexibles with filters and solenoid valves M⅜".
Fixing reinforced by 2 stainless steel rods.
Anti-blocking security.
Spout with smooth interior and low water volume (reduces bacterial development).
Side temperature control with adjustable maximum temperature and long lever.
Drop height 170mm for semi-recessed washbasins.
Suitable for people with reduced mobility.
TECHNICAL CHARACTERISTICS
BLACK BINOPTIC MIX electronic mixer
Ref. 488MCHBSupply | 6V batteries |
Connector | M3/8" |
Technology | Electronic |
Drop height | 170mm |
Spout length | 175mm |
Flow rate | 3 lpm |
Finish | Matte black chrome |
Delabie бесконтактный электронный смеситель 250mm 398MCHB M3/8" BINOPTIC MIX 230/12V матовый чёрный
Delabie kontaktivaba elektronik segisti 250mm 398MCHB M3/8" BINOPTIC MIX 230/12V matt must
BLACK BINOPTIC MIX electronic mixer
Ref. 398MCHB
Independent IP65 electronic control unit.
230/12V mains supply with transformer.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.
Scale-resistant flow straightener.
Adjustable duty flush (pre-set flush 60 seconds every 24 hours after last use).
Active, infrared presence detection, sensor at the end of the spout optimises detection.
Chrome-plated brass body.
Matte black chrome finish
PEX flexibles with filters and solenoid valves M⅜".
Fixing reinforced by 2 stainless steel rods.
Anti-blocking security.
Spout with smooth interior and low water volume (reduces bacterial development).
Side temperature control with adjustable maximum temperature limiter and long lever.
Drop height 250mm for countertop washbasins.
Suitable for people with reduced mobility.
TECHNICAL CHARACTERISTICS
BLACK BINOPTIC MIX electronic mixer
Ref. 398MCHBSupply | Mains supply 230/12V |
Connector | M3/8" |
Technology | Electronic |
Drop height | 250mm |
Spout length | 185mm |
Flow rate | 3 lpm |
Finish | Matte black chrome |
BLACK BINOPTIC MIX electronic mixer
Ref. 498MCHB
Independent IP65 electronic control unit.
123 6V Lithium batteries.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 - 6 lpm.
Scale-resistant flow straightener.
Adjustable duty flush (pre-set flush 60 seconds every 24 hours after last use).
Active, infrared presence detection, sensor at the end of the spout optimises detection.
Chrome-plated brass body.
Matte black chrome finish.
PEX flexibles with filters and solenoid valves M⅜".
Fixing reinforced by 2 stainless steel rods.
Anti-blocking security.
Spout with smooth interior and low water volume (reduces bacterial development).
Side temperature control with adjustable maximum temperature and long lever.
Drop height 250mm for counter-top washbasins.
Suitable for people with reduced mobility.
TECHNICAL CHARACTERISTICS
BLACK BINOPTIC MIX electronic mixer
Ref. 498MCHBSupply | 6V batteries |
Connector | M3/8" |
Technology | Electronic |
Drop height | 250mm |
Spout length | 185mm |
Flow rate | 3 lpm |
Finish | Matte black chrome |
Delabie бесконтактный электронный смеситель 378MCHB M3/8" BINOPTIC MIX 230/12V матовый чёрный
Delabie kontaktivaba elektronik segisti 378MCHB M3/8" BINOPTIC MIX 230/12V matt must
BLACK BINOPTIC MIX electronic mixer
Ref. 378MCHB
Independent IP65 electronic control unit.
230/12V mains supply with transformer.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 to 6 lpm.
Scale-resistant flow straightener.
Adjustable duty flush (pre-set flush ~60 seconds every 24 hours after last use).
Active infrared presence detection, sensor at the end of the spout optimises detection.
Chrome-plated brass body.
Matte black chrome finish.
PEX flexibles with filters and solenoid valves M3/8".
Fixing reinforced by 2 stainless steel rods.
Anti-blocking safety.
Spout with smooth interior and low volume of water (reduces niches where bacteria can develop).
Side temperature control with standard lever and adjustable maximum temperature limiter.
Suitable for people with reduced mobility.
TECHNICAL CHARACTERISTICS
BLACK BINOPTIC MIX electronic mixer
Ref. 378MCHB
Supply | Mains supply 230/12V |
Connector | M3/8" |
Technology | Electronic |
Drop height | 110mm |
Spout length | 135mm |
Flow rate | 3 lpm |
Finish | Matte black chrome |
Delabie бесконтактный электронный смеситель 478MCHB M3/8" BINOPTIC MIX 6V матовый чёрный
Delabie kontaktivaba elektronik segisti 478MCHB M3/8" BINOPTIC MIX 6V matt must
BLACK BINOPTIC MIX electronic mixer
Ref. 478MCHB
Independent IP65 electronic control unit.
123 6V Lithium battery-operated.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 to 6 lpm.
Scale-resistant flow straightener.
Adjustable duty flush (pre-set flush ~60 seconds. every 24 hours after last use).
Active, infrared presence detection, sensor at the end of the spout optimises detection.
Chrome-plated brass body.
Matte black chrome finish.
PEX flexibles with filters and solenoid valves M3/8".
Fixing reinforced by 2 stainless steel rods.
Anti-blocking safety.
Spout with smooth interior and low volume of water(reduces niches where bacteria can develop).
Side temperature control with standard lever control and adjustable maximum temperature limiter.
Suitable for people with reduced mobility.
TECHNICAL CHARACTERISTICS
BLACK BINOPTIC MIX electronic mixer
Ref. 478MCHBSupply | 6V batteries |
Connector | M3/8" |
Technology | Electronic |
Drop height | 110mm |
Spout length | 135mm |
Flow rate | 3 lpm |
Finish | Matte black chrome |
Delabie настенный электронный кран на смешанную воду 379MCHB M3/8" BINOPTIC TAP 230/12V матовый чёрный
Delabie kontaktivaba eelsegatud/külmavee kraan seinale 379MCHB BINOPTIC MIX 230/12V matt must
BLACK BINOPTIC electronic tap
Ref. 379ENCB
Independent IP65 electronic control unit.
230/12V mains supply with transformer.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 to 6 lpm.
Scale-resistant flow straightener.
Adjustable duty flush (pre-set flush ~60 seconds every 24 hours after last use).
Active, infrared presence detection, sensor at the end of the spout optimises detection.
Filter and solenoid valve M3/8".
Chrome-plated brass body.
Matte black chrome finish.
Recessed installation.
Anti-blocking safety.
Spout with smooth interior and low volume of water (limits bacterial niches).
Suitable for people with reduced mobility.
TECHNICAL CHARACTERISTICS
BLACK BINOPTIC electronic tap
Ref. 379ENCBSupply | Mains supply 230/12V |
Connector | M3/8" |
Technology | Electronic |
Spout length | 200mm |
Flow rate | 3 lpm |
Finish | Matte black chrome |
Delabie настенный электронный смеситель 379MCHB M3/8" BINOPTIC MIX 230/12V матовый чёрный
Delabie kontaktivaba elektronik segisti seinale 379MCHB BINOPTIC MIX 230/12V matt must
BLACK BINOPTIC MIX electronic mixer
Ref. 379MCHB
Independent IP65 electronic control unit.
230/12V mains supply with transformer.
Flow rate pre-set at 3 lpm at 3 bar, can be adjusted from 1.4 to 6 lpm.
Scale-resistant flow straightener.
Adjustable duty flush (pre-set flush ~60 seconds every 24 hours after last use).
Active, infrared presence detection, sensor at the end of the spout optimises detection.
Filters and solenoid valves M3/8".
Chrome-plated brass body.
Matte black chrome finish.
Cross wall installation ≤110mm
Cable for sensor L. 120mm, flexibles and mounting all pass through the same hole.
Anti-blocking safety.
Spout with smooth interior and low volume of water (reduces bacterial niches).
Side temperature control with standard lever and adjustable maximum temperature limiter.
Suitable for people with reduced mobility.
TECHNICAL CHARACTERISTICS
BLACK BINOPTIC MIX electronic mixer
Ref. 379MCHBSupply | Mains supply 230/12V |
Connector | M3/8" |
Technology | Electronic |
Spout length | 230mm |
Flow rate | 3 lpm |
Finish | Matte black chrome |
Delabie рукосушилка HIGHFLOW скорость 10-15 сек, Н/Р сталь чёрная
Delabie Kätekuivati HIGHFLOW kiir 10-15 sek, RST teras must
HIGHFLOW automatic air pulse hand dryer in matte black
Ref. 510622BK
Robust model.
Lit central nozzle focuses the pulsed air onto hands at over 230km/h.
High speed: dries in 10 - 12 seconds.
Choice of warm or cold air via a concealed switch.
Infrared automatic activation.
Intelligent technology: stops automatically when hands are removed.
Anti-blocking: stops automatically if used continuously for more than 60 seconds.
Electrical hand dryer made from matte black bacteriostatic 304 stainless steel.
Easy to clean: one-piece cover.
Stainless steel thickness: 1mm.
Dimensions: 175 x 238 x 267mm.
Weight: 4kg.
Airflow: 39 l/second.
Air speed: 230 km/h.
Low energy consumption: 1,350W.
220-240 V~ / 50 Hz.
Noise level: 70 dBA.
Class I, IP23.
CE marked.
TECHNICAL CHARACTERISTICS
HIGHFLOW automatic air pulse hand dryer in matte black
Ref. 510622BKTechnology | Infrared sensor |
Height | 267mm |
Depth | 175mm |
Width | 238mm |
Finish | Matte black 304 stainless steel |
