Лабораторя, Химический класс
Alamgrupid
Broen 1-й , душ для промывки глаз, сквозь столешницу, Н/Р сталь
Broen 1-le silmadele 45", hädaabi silmadušš, lääbiviik
Min. working pressure: 1.5 bar for all Eye Showers
No. 27 10 003 10 05 011
Weight: Approx. 0.5 kg
Table mounted eye shower with
a single 45° head, incl. 1.5m inlet hose. Trigger operated including a built-in check valve and FLOWFIX for regulation of water flow (7 l/min).
Min. working pressure: 1,5 bar.
Min. working pressure: 1.5 bar for all Eye Showers
Min. working pressure: 1.5 bar for all Eye Showers
Min. working pressure: 1.5 bar for all Eye Showers
Min. working pressure: 1.5 bar for all Eye Showers
Sees 492x282 (vajab põhjaklappi 97B0073)
Broen Lab PP лабораторная раковина 552x400x235 (PxLxK) белая
Sees 492x282 (vajab põhjaklappi 97B0073)
PRODUCT NUMBER 97B0810
FOR WASTE CONNECTION
S P E C I F I C AT I O N S
Temperature range: 0-80°C
Standard colour: black (other colours available on request ) Net weight: 5.4 kg
Dimensions: external 807 x 469 x 330mm (tolerance ± 1mm)
The largest polypropylene sink offered, it is suitable for cleansing of larger items. Very widely used in island benches and teacher benches.
Broen Lab PP раковина лабораторная 418x316x220 (PxLxK) Нужен клапан 97B0073
PP labori valamu 418x216x320 (PxLxK) (vajab põhjaklappi 97B0073)
S P E C I F I C AT I O N S
Temperature range: 0-80°C
Standard colour: black (other colours available on request) Net weight: 1.4 kg
Dimensions: bxternal 418 x 316 x 220mm (tolerance ± 1mm)
Injection moulded from polypropylene copolymer resin, with
a self-draining base. Designed for mounting on top or underside of the work benches.
Min. working pressure: 1.5 bar for all Eye Showers
Min. working pressure: 1.5 bar for all Eye Showers
PRINCIPLE SKETCH STABILET® EL / STABILINE® EL
1. Outlet including infrared sensor. Reacts when an object is in front of the spout.
2. Electronic box including transformer from mains to 12V DC.
3. STABILET® EL or STABILINE® EL valve. SPECIFICATIONS, ELECTRONIC BOX Mains voltage: 220V, 50 Hz phase, neutral and earth. Other voltage on request Operating voltage: 12V DC. Short circuit safety transformer Power consumption: Idling: 3 W. / Working: 3.5 W Built-in control of max. flow time of 45 sec Adjustable operating distance, min. 5 cm, max. 50 cm Waterproof plastic box and cable entries, IP 65 Cable length: From electronic box to STABILET EL®/ STABILINE EL®: 100 cm From electronic box to sensor: (spout)100 cm Screws and plugs included
750,30 €
Wall-mounted eye wash station
Ref. 9102
Wall-mounted eye wash station with manual control includes:
304 stainless steel basin Ø 250mm, green powder-coated finish.
Two spray heads fitted with protective caps in shock-resistant green ABS; will eject automatically when activated.
1/4-turn, nickel-plated brass valve opens and closes quickly.
Water flow is activated by the hand control. The eye wash will continue to operate when the hand control is released. The water flow will stop when the hand control is pulled towards the user.
Flow rate 20 lpm at 3 bar.
Aerators with stainless steel double filters.
Water supply M1/2".
Pipework made from galvanised steel, grey powder-coated finish.
Hand control made from galvanised steel, green powder-coated finish.
Wall-mounted on a brass plate (screws not included.)
Supplied with identification sign for first aid equipment: "Eye Wash"
TECHNICAL FEATURES
Wall-mounted eye wash station
Ref. 9102
| Supply | M1/2" |
|---|---|
| Height | 195mm |
| Flow rate | 20 lpm |
| Width to the wall | 204mm |
| Finish | Epoxy |
Free-standing eye wash station
Ref. 9201
Free-standing eye wash station with manual and pedal control includes:
Frost-free system as standard.
304 stainless steel basin Ø 250mm, green powder-coated finish.
2 eye wash spray heads fitted with protective caps in shock-resistant green ABS; will eject automatically when activated.
1/4-turn, nickel-plated brass valves open and close quickly.
Water flow is activated by hand or foot control. The eye wash will continue to operate when the hand or foot control is released. The flow stops when the hand control is pulled towards the user or the foot pedal is raised.
Flow rate 20 lpm at 3 bar.
Aerators with stainless steel double filters.
Water supply F1".
Pipework made from galvanised steel, grey powder-coated finish.
Hand and foot controls in green powder-coated galvanised steel.
Fixed to the floor by a triangular brass plate (screws not included.)
Supplied with identification sign for first aid equipment: "Eye Wash".
TECHNICAL FEATURES
Free-standing eye wash station
Ref. 9201
| Height | 1050mm |
|---|---|
| Depth | 500mm |
| Flow rate | 20 lpm |
| Finish | Epoxy |
Wall-mounted safety shower
Ref. 9108
Wall-mounted safety shower with manual control includes:
Frost-free system as standard.
Circular shower head Ø 250mm in green, shock-resistant ABS.
1/4-turn, nickel-plated brass valve opens and closes quickly.
Water flows simply by pulling on the triangular handle.
The flow will continue even when the handle is released.
The flow will stop when the handle is returned to its original position.
Flow rate 70 lpm at 1 bar dynamic pressure (120 lpm at 3 bar dynamic pressure).
Water supply F1".
Pipework made from galvanised steel, grey powder-coated finish. Triangular pull handle in green powder-coated brass.
Supplied with identification sign for first aid equipment: "Safety Shower".
For cross wall installation, with recessed supply, or for mounting on a false ceiling (we recommend a 1" mounting bracket).
TECHNICAL FEATURES
Wall-mounted safety shower
Ref. 9108
| Supply | F1" |
|---|---|
| Height | 450mm |
| Length | 625mm |
| Flow rate | 120 lpm at 3 bar dynamic pressure |
| Finish | Epoxy |
Eye wash and safety shower combination
Ref. 9203
Free-standing eye wash and safety shower combination with manual or foot control includes:
Frost-free system as standard.
304 stainless steel basin Ø 250mm with green finish.
Eye wash spray heads fitted with protective caps in shock-resistant green ABS; will eject automatically when activated.
Flow rate 20 lpm at 3 bar, aerators have stainless steel double filters.
Circular shower head Ø 250mm in green, shock-resistant ABS.
Flow rate 70 lpm at 1 bar dynamic pressure (120 lpm at 3 bar dynamic pressure).
Water supply F1".
Pipework made from galvanised steel, grey powder-coated finish. Triangular pull handle in green powder-coated brass. Hand and foot controls in green powder-coated galvanised steel.
Fixed to the floor by a brass base plate (screws not included).
Supplied with identification signs for first aid equipment: "Safety Shower" and "Eye Wash".
Operation:
1/4-turn, nickel plated brass valves open and close quickly.
Simultaneous Eye Wash and Shower:
Water flows simply by pulling on the triangular handle.
The flow will continue even when the handle is released.
The flow will stop when the handle is returned to its original position.
Eye Wash only:
Water flow is operated by the foot pedal or the hand control. The eye wash will continue to flow when the pedal or hand control is released.
The water flow will stop when the hand control is pulled towards the user or the foot pedal is raised.
10-year warranty.
The water does not shut off automatically, allowing the injured person to have both hands free (to remove their clothing, keep their eyes open, etc.).
TECHNICAL FEATURES
Eye wash and safety shower combination
Ref. 9203
| Supply | F1" |
|---|---|
| Height | 2207mm |
| Length | 660mm |
| Drop height | 2115mm |
| Flow rate | 120 lpm at 3 bar dynamic pressure |
SECURITHERM BIOCLIP thermostatic sink mixer
Ref. H9611P
Sequential: opens and closes with cold water.
Supplied with 2 removable BIOCLIP stainless steel spouts L. 136mm.
Anti-scalding failsafe: immediate shut-off if cold or hot water supply fails.
Securitouch thermal insulation prevents burns.
No risk of cross flow between hot and cold water.
No non-return valves on the inlets.
Scale-resistant sequential thermostatic cartridge.
Temperature control: cold water up to 40°C. Temperature limiter set at 40°C.
Thermal or chemical shocks are possible.
Body and spout with smooth interiors and low water volume.
Flow rate regulated at 7 lpm.
No manual contact thanks to Hygiene control lever L. 146mm.
Mixer with 150mm centres, supplied with in-line STOP/CHECK connectors ideal for hospitals.
Chrome-plated brass body.
TECHNICAL CHARACTERISTICS
SECURITHERM BIOCLIP thermostatic sink mixer
Ref. H9611P| Connector | M1/2" |
| Technology | SECURITHERM BIOCLIP sequential, Securitouch |
| Height | 141mm |
| Width | 184mm |
| Spout length | 136mm |
| Flow rate | 7 lpm |
| Temperature limiter | 40°C |
| Finish | Chrome-plated brass |
675,00 €
Bucket sink in stainless steel for wall mounting. Supplied with stainless steel wall panel, supporting bracket and 3 1/2" x 2" waste with plug and overflow.
341,60 €
Sees 290x290 (vajab põhjaklappi 97B0073)
