> Working pressure :
1 to 5 bar
> Flow :
3 l/min with integrated flow limiter
High quality anti-limescale aerator (new aerator since June 2016) Anti-water-hammering design
> Hydraulic supply :
G 3/8" (12x17)
> Power supply :
6 V lithium battery (CRP2 type) in a casing placed within the tap body
> Material and colour finish :
Chrome-plated metal alloy components Injected molded metal body and cover
> Thermal resistance :
Resistant to a temperature of 75°C for 30-minute-thermal-shocks
> Security :
Temperature limiting system to avoid any risk of scalding
Anti-overflow security time: 30 seconds
Anti-blocking system preventing the water to flow continuously
Solenoid valve automatically shut down in case of power shortage or in case of sensor degradation
> Delivered with :
Instruction manual
2 Fastening nuts
1 Gasket and 1 Washer
2 PEX flexible hoses with F 3/8'' nut (12x17) and NF non-return valve 2 Straight stop valves G 3/8" (12x17)
2 Filter gaskets
> Standards & approvals :
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
Range: SO'O
Ref: 56198 - Deck-mounted mixer sensor tap - Mains-operated - Black and pink gold cover
132
Powered by TCPDF (www.tcpdf.org)
> Working pressure :
1 to 5 bar
> Flow :
3 l/min with integrated flow regulator High quality anti-limescale aerator Anti-water-hammering design
> Hydraulic supply :
G 3/8" (12x17)
> Power supply :
230 VAC/7 VDC transformer in IP65 waterproof case
> Material and colour finish :
Chrome-plated metal alloy components Injected molded metal body and cover Black finish with pink gold cover
> Thermal resistance :
Resistant to a temperature of 75°C for 30-minute-thermal-shocks
> Security :
Temperature limited by adjustable stop
Anti-overflow security time: 30 seconds
Anti-blocking system preventing the water to flow continuously
Solenoid valve automatically shut down in case of power shortage or in case of sensor degradation
> Delivered with:
2 Fastening nuts
1 Gasket and 1 Washer
2 PEX flexible hoses with F 3/8'' nut (12x17) and NF non-return valve 2 Straight stop valves G 3/8" (12x17)
2 Filter gaskets
Instructions manual
> Standards & approvals :
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
> Working pressure :
1 to 5 bar
> Flow :
3 l/min with integrated flow limiter
High quality anti-limescale aerator (new aerator since June 2016) Anti-water-hammering design
> Hydraulic supply :
G 3/8" (12x17)
> Power supply :
6 V lithium battery (CRP2 type) in a casing placed within the tap body
> Material and colour finish :
Chrome-plated metal alloy components Injected molded metal body and cover
> Thermal resistance :
Resistant to a temperature of 75°C for 30-minute-thermal-shocks
> Security :
Temperature limiting system to avoid any risk of scalding
Anti-overflow security time: 30 seconds
Anti-blocking system preventing the water to flow continuously
Solenoid valve automatically shut down in case of power shortage or in case of sensor degradation
> Delivered with :
Instruction manual
2 Fastening nuts
1 Gasket and 1 Washer
2 PEX flexible hoses with F 3/8'' nut (12x17) and NF non-return valve 2 Straight stop valves G 3/8" (12x17)
2 Filter gaskets
> Standards & approvals :
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
> Working pressure :
1 to 5 bar
> Flow :
3 l/min with integrated flow limiter
High quality anti-limescale aerator (new aerator since June 2016) Anti-water-hammering design
> Hydraulic supply :
G 3/8" (12x17)
> Power supply :
6 V lithium battery (CRP2 type) in a casing placed within the tap body
> Material and colour finish :
Chrome-plated metal alloy components
Injected molded metal body and cover
150mm extended body
Distance from the base up to the detection cell: 205 mm
> Thermal resistance :
Resistant to a temperature of 75°C for 30-minute-thermal-shocks
> Security :
Temperature limiting system to avoid any risk of scalding
Anti-overflow security time: 30 seconds
Anti-blocking system preventing the water to flow continuously
Solenoid valve automatically shut down in case of power shortage or in case of sensor degradation
> Delivered with :
Instruction manual
2 Fastening nuts
1 Gasket and 1 Washer
2 PEX flexible hoses with F 3/8'' nut (12x17) and NF non-return valve 2 Straight stop valves G 3/8" (12x17)
2 Filter gaskets
> Standards & approvals :
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
> Working pressure :
1 to 5 bar
> Flow :
3 l/min with integrated flow limiter
High quality anti-limescale aerator (new aerator since June 2016) Anti-water-hammering design
> Hydraulic supply :
G 3/8’’ (12x17)
> Power supply :
6 V lithium battery (CRP2 type) in a casing placed within the tap body
> Material and colour finish :
Chrome-plated metal alloy components Injected molded metal body and cover White cover
> Thermal resistance :
Resistant to a temperature of 75°C for 30-minute-thermal-shocks
> Security :
Temperature limiting system to avoid any risk of scalding
Anti-overflow security time: 30 seconds
Anti-blocking system preventing the water to flow continuously
Solenoid valve automatically shut down in case of power shortage or in case of sensor degradation
> Delivered with :
Instruction manual
2 Fastening nuts
1 Gasket and 1 Washer
2 PEX flexible hoses with F 3/8'' nut (12x17) and NF non-return valve 2 Straight stop valves G 3/8" (12x17)
2 Filter gaskets
> Standards & approvals :
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
> Working pressure :
1 to 5 bar
> Flow :
3 l/min with integrated flow limiter
High quality anti-limescale aerator (new aerator since June 2016) Anti-water-hammering design
> Hydraulic supply :
G 3/8’’ (12x17)
> Power supply :
6 V lithium battery (CRP2 type) in a casing placed within the tap body
> Material and colour finish :
Chrome-plated metal alloy components
Injected molded metal body and cover
Distance from the base up to the detection cell: 205 mm White cover
> Thermal resistance :
Resistant to a temperature of 75°C for 30-minute-thermal-shocks
> Security :
Temperature limiting system to avoid any risk of scalding
Anti-overflow security time: 30 seconds
Anti-blocking system preventing the water to flow continuously
Solenoid valve automatically shut down in case of power shortage or in case of sensor degradation
> Delivered with :
Instruction manual
2 Fastening nuts
1 Gasket and 1 Washer
2 PEX flexible hoses with F 3/8'' nut (12x17) and NF non-return valve 2 Straight stop valves G 3/8" (12x17)
2 Filter gaskets
> Standards & approvals :
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
> Working pressure :
1 to 5 bar
> Flow :
3 l/min with integrated flow limiter
High quality anti-limescale aerator (new aerator since June 2016) Anti-water-hammering design
> Hydraulic supply :
G 3/8’’ (12x17)
> Power supply :
6 V lithium battery (CRP2 type) in a casing placed within the tap body
> Material and colour finish :
Chrome-plated metal alloy components Injected molded metal body and cover Black cover
> Thermal resistance :
Resistant to a temperature of 75°C for 30-minute-thermal-shocks
> Security :
Temperature limiting system to avoid any risk of scalding
Anti-overflow security time: 30 seconds
Anti-blocking system preventing the water to flow continuously
Solenoid valve automatically shut down in case of power shortage or in case of sensor degradation
> Delivered with :
Instruction manual
2 Fastening nuts
1 Gasket and 1 Washer
2 PEX flexible hoses with F 3/8'' nut (12x17) and NF non-return valve 2 Straight stop valves G 3/8" (12x17)
2 Filter gaskets
> Standards & approvals :
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
> Working pressure :
1 to 5 bar
> Flow :
3 l/min with integrated flow limiter
High quality anti-limescale aerator (new aerator since June 2016) Anti-water-hammering design
> Hydraulic supply :
G 3/8’’ (12x17)
> Power supply :
6 V lithium battery (CRP2 type) in a casing placed within the tap body
> Material and colour finish :
Chrome-plated metal alloy components
Injected molded metal body and cover
Distance from the base up to the detection cell: 205 mm Black cover
> Thermal resistance :
Resistant to a temperature of 75°C for 30-minute-thermal-shocks
> Security :
Temperature limiting system to avoid any risk of scalding
Anti-overflow security time: 30 seconds
Anti-blocking system preventing the water to flow continuously
Solenoid valve automatically shut down in case of power shortage or in case of sensor degradation
> Delivered with :
Instruction manual
2 Fastening nuts
1 Gasket and 1 Washer
2 PEX flexible hoses with F 3/8'' nut (12x17) and NF non-return valve 2 Straight stop valves G 3/8" (12x17)
2 Filter gaskets
> Standards & approvals :
Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
Range: SO'O
Ref: 56196 - Deck-mounted mixer sensor tap - Battery - Black and pink gold cover
132
Powered by TCPDF (www.tcpdf.org)
> Working pressure :
1 to 5 bar
> Flow :
3 l/min with integrated flow regulator High quality anti-limescale aerator Anti-water-hammering design
> Hydraulic supply :
G 3/8" (12x17)
> Power supply :
6 V lithium battery (CRP2 type) in a casing placed within the tap body
> Material and colour finish :
Chrome-plated metal alloy components Injected molded metal body and cover Black finish with pink gold cover
> Thermal resistance :
Resistant to a temperature of 75°C for 30-minute-thermal-shocks
> Security :
Temperature limited by adjustable stop
Anti-overflow security time: 30 seconds
Anti-blocking system preventing the water to flow continuously
Solenoid valve automatically shut down in case of power shortage or in case of sensor degradation
> Delivered with:
2 Fastening nuts
1 Gasket and 1 Washer
2 PEX flexible hoses with F 3/8'' nut (12x17) and NF non-return valve 2 Straight stop valves G 3/8" (12x17)
2 Filter gaskets
Instructions manual
> Standards & approvals :
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
