Смесители из нержавеющей стали Wagner Ewar

for WA100 - 210
(from 2018)

86 x 34 x 25 mm
0,5 kg

SUITABLE FOR:

• WA 100
• WA 100-1
• WA 110
• WA 110-1
• WA 200
• WA 200-1
• WA 210
• WA 210-1

50 x 172 x 161 mm
normal pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: normal pressure. Operating pressure 2–6 bar.
• Solid rectangular stainless steel body; visible surfaces satin finished. Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M24 x 1 mm.
• Design height: 172 mm
  Outlet height: 92 mm
  Projection: 97 mm
  Length of lever: 65 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.

• Weight (in kg): 2,3

50 x 172 x 161 mm
normal pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: normal pressure. Operating pressure 2–6 bar.
• Solid rectangular stainless steel body; visible surfaces satin finished. Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M24 x 1 mm.
• Design height: 172 mm
  Outlet height: 92 mm
  Projection: 97 mm
  Length of lever: 65 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.

• Weight (in kg): 2,3

Ø 45 x 170 x 155 mm
normal pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: normal pressure. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M22 x 1 mm.
• Design height: 171 mm
  Outlet height: 87 mm
  Projection: 98 mm
  Length of lever: 40 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.

• Weight (in kg): 1,60

Ø 45 x 170 x 155 mm
normal pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: normal pressure. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M22 x 1 mm.
• Design height: 171 mm
  Outlet height: 87 mm
  Projection: 98 mm
  Length of lever: 40 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.

• Weight (in kg): 1,60

Ø 45 x 283 x 185 mm
normal pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: normal pressure. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 283 mm
  Outlet height: 199 mm
  Projection: 98 mm
  Length of lever: 140 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.

• Weight (in kg): 1,70

Ø 45 x 283 x 185 mm
normal pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: normal pressure. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 283 mm
  Outlet height: 199 mm
  Projection: 98 mm
  Length of lever: 140 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.

• Weight (in kg): 1,70

Ø 45 x 283 x 185 mm
normal pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: normal pressure. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 283 mm
  Outlet height: 199 mm
  Projection: 98 mm
  Length of lever: 140 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.

• Weight (in kg): 1,70

Ø 45 x 170 x 185 mm
normal pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: normal pressure. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 171 mm
  Outlet height: 87 mm
  Projection: 98 mm
  Length of lever: 140 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.

• Weight (in kg): 1,60

Ø 45 x 170 x 185 mm
normal pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: normal pressure. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 171 mm
  Outlet height: 87 mm
  Projection: 98 mm
  Length of lever: 140 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.

• Weight (in kg): 1,60

Ø 45 x 170 x 185 mm
normal pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: normal pressure. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 171 mm
  Outlet height: 87 mm
  Projection: 98 mm
  Length of lever: 140 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.

• Weight (in kg): 1,60

Ø 45 x 170 x 185 mm
low pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 171 mm
  Outlet height: 87 mm
  Projection: 98 mm
  Length of lever: 140 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.

• Weight (in kg): 1,90

Ø 45 x 170 x 155 mm
low pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 171 mm
  Outlet height: 87 mm
  Projection: 98 mm
  Length of lever: 40 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.

• Weight (in kg): 1,90

Ø 45 x 170 x 185 mm
low pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 171 mm
  Outlet height: 87 mm
  Projection: 98 mm
  Length of lever: 140 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.

• Weight (in kg): 1,90

Ø 45 x 170 x 155 mm
low pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 171 mm
  Outlet height: 87 mm
  Projection: 98 mm
  Length of lever: 40 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.

• Weight (in kg): 1,90

Ø 45 x 283 x 155 mm
low pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 283 mm
  Outlet height: 199 mm
  Projection: 98 mm
  Length of lever: 40 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm, surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.

• Weight (in kg): 2,00

Ø 45 x 283 x 185 mm
low pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 283 mm
  Outlet height: 199 mm
  Projection: 98 mm
  Length of lever: 140 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm, surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and three flexiblen, stainless steel covered connecting tubes.

• Weight (in kg): 2,00

Ø 45 x 283 x 155 mm
low pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 283 mm
  Outlet height: 199 mm
  Projection: 98 mm
  Length of lever: 40 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm, surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and three flexible connecting hoses clad in stainless steel.

• Weight (in kg): 2,00

Ø 45 x 283 x 185 mm
low pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: low pressure, suitable for unpressurised tanks. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 283 mm
  Outlet height: 199 mm
  Projection: 98 mm
  Length of lever: 140 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm, surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and three flexiblen, stainless steel covered connecting tubes.

• Weight (in kg): 2,00
